Description
Basic Info.
Model NO.
QXC9400GRYC
Function
Storage Pressure Vessel, Separation Pressure Vessel, Heat Pressure Vessel, Reaction Pressure Vessel
Application
Liquefied Gas
Material
SA-516, SA-517, SA-612, P460, Q420r, Q370r, etc.Hi
Pressure
0.1MPa≤p<1.6MPa
Storage Medium
Flammable/Toxic
Pressure Level
Low Pressure (0.1MPa≤p<1.6MPa)
Condition
New
Product Name
LPG Trailer
Safety Control System
Safety Valve, Pressure Meter, Cut-off Valve
Safety Release Type
Built-in Full-Lift Spring Safety Valve
Nominal Pressure
2.5 MPa
Work Stress
≤2.2 MPa
Operating Mode
Manual Operation
Filling Capacity Per Unit Volume
550 Kg/M³
Reference Model
Na42f-25 / Qgj43f-25p
Media Name
Liquefied Petroleum Gas (LPG)
Thermometer
2.5 Class
Closure Time
5 Seconds
Nominal Diameter
Gas Phase DN25, Liquid Phase DN50
Proof Pressure
3.03MPa Water Pressure Test
Max Payload
30tons
HS
8716900000
Transport Package
Bare Bag
Specification
12550*2550*3850mm
Trademark
QXC
Origin
China
HS Code
8716900000
Production Capacity
50000pieces/Year
Packaging & Delivery
Package Size
1250.00cm * 255.00cm * 289.00cm
Package Gross Weight
11500.000kg
Product Description
HONGXING SPECIAL AUTOMOBILE CO.LTD,
*ASME standard available*
*100% new condition by manufacturer direct sale*
*ASME standard available*
*100% new condition by manufacturer direct sale*
| ASME Standard | ||||
| Capacity | Diameter x Height x Length | Tank Weight | Payload | Thickness |
| 10m3 | φ1600×2440×5308mm | 3850kg | 4630kg | Shell 11.09mm/Head 11.02mm |
| 20m3 | φ2200×3050×5690mm | 6920kg | 9260kg | Shell 14.86mm/Head 14.78mm |
| 32m3 | φ2200×3050×8860mm | 9750kg | 14820kg | |
| 40m3 | φ2470×3320×8851mm | 11930kg | 18530kg | Shell 16.56mm/Head 16.47mm |
| 50m3 | φ2470×3320×10911mm | 15420kg | 25470kg | |
| 60m3 | φ2470×3320×13001mm | 16600kg | 27790kg | |
| 80m3 | φ3100×3960×11178mm | 22820kg | 37060kg | Shell 20.53mm/Head 20.41mm |
| 100m3 | φ3100×3960×13858mm | 27430kg | 46320kg | |
| 120m3 | φ3200×3542×16100mm | 26100kg | 51000kg | Shell 20.14mm/Head 10.07mm |
| 150m3 | φ3300×4210×18158mm | 39930kg | 69480kg | Shell 21.79mm/Head 21.66mm |
| Main Material | SA-516 Gr.70 | Design Pressure | 1.724Mpa | |
| Hydraulic Test Pressure | 2.25Mpa | Working Pressure | ≤1.724Mpa | |
| Corrosion Allowance | 1mm | Design Temperature | 50ºC | |
| Specific Gravity | 0.545@15ºC | Working Temperature | -20~50ºC | |
